DS-ET365P/185P high sensitivity Sony Exwave HAD CCD, with advanced DSP technology, get 540 lines of resolution, clarity and detail, true color, high-quality images; configure Automatic day and night, so that these cameras at night can also provide excellent image. SSC-ET365P provides up to 36 times as large optical zoom, SSC-ET185P offers 18x optical zoom. This series of high-performance integrated camera uses Sony's advanced DynaView technology, providing up to 128 times the wide dynamic range, even in low-light contrasts environment for clear image; addition, advanced slow AE response function make these cameras in the monitored area when a sudden change in lighting conditions to maintain a clear image output.

DS-ET365P/185P set in a variety of advanced features and compact design, stylish appearance, banks, transportation, intelligent buildings, shopping malls, supermarkets, hotels, sports stadiums, hospitals, government agencies, public security and other industries ideal for surveillance applications.



Product Type

DS-ET365P

Imaging Device

1/4 inch Exwave HAD CCD

Effective Pixels

440,000

Zoom

432 times (36x optical, 12x digital)

Focal length

f = 3.4mm ~ 122.4m

F value

F1.6 (wide) ~ F4.5 (tele

Horizontal viewing angle

57.8 ~ 1.7 °

Day and night functionality

Support

Minimum illumination

Color: 0.8Lx, black and white: 0.007Lx (F1.6, 30IRE)

Color: 1.4Lx, black and white: 0.01Lx (F1.6, 50IRE)

SNR

50dB

Dynamic Range

52dB

Electronic Shutter

1 to 1/10, 000 sec.

White Balance

ATW PRO, ATW, indoor, outdoor, one-touch, manual

Gain

Auto / Manual

Exposure Control

Auto, Manual, Priority mode, brightness, EV compensation, Backlight compensation, slow exposure, wide dynamic

WDR

ON / OFF

EV Compensation

-10.5 ~ +10.5 DB

BLC

ON / OFF

Collecting system

Auto (Sensitivity: normal, low), one-touch, manual, unlimited, automatic aggregation interval

Privacy Zone Masking

On / Off (24 positions)

Preset

6

Iris control

Step 16

Image Effects

Freeze, electronic flip, anti-color, black and white, mirror

Camera control buttons

Zoom (away), Zoom (nearly), aggregation (much), aggregates (nearly)

Synchronization system

Internal / Line Lock

Camera control protocol

VISCA protocol, baud rate: 9.6Kbps, 19.2Kbps, 38.4Kbps, 1 or 2 stop bits selectable

Storage Temperature

-20 ~ 60 ℃

Operating Temperature

0 ~ 40 ℃

Power requirements

AC24V/DC12V

Power

5.2W

Quality

470g

Dimensions (W × H × D)

59.4 × 65.4 × 120mm
