Camera main technical parameters:
-1 / 3 SONY E xView CCD definition 700VL
- Zoom magnification: 26x optical
- Built-in Chinese and English menu
- With power and memory function
- Light suppression, 2D noise reduction
- Automatic tracking white balance, automatic gain.
- Focal Length f = 3.6 - 97.2MM
- Dual filter day / night: automatic switching / link switch
-850 Nm infrared transmittance ≥ 89% super
- Minimum illumination: Color 0.2 lux (normal), black and white 0.02 LUX (real-time)
- Signal-to-noise ratio ≥ 52dB
- High-speed shutter - Auto / 1/50-1/10, 000SEC
- Mirror: Support level
- Backlight compensation: (NO / OFF) / light inhibition (HSBLC)
- Automatic gain AGC: (0-15) adjustable amplitude
- White balance settings: Auto / Auto Tracking / Indoor / Outdoor / Manual mode
-2D Digital Noise Reduction: On / Off
Ball machine performance characteristics
● OSRAM High Power dot infrared LED, energy-efficient
Infrared light and magnification distance matching algorithm based on magnification and distance to adjust the brightness of the infrared light, the image to achieve the desired state
● Built-in heat treatment device, reduce the temperature of the dome cavity to prevent the fogging of the inner cover of the ball machine
● the use of constant current - constant voltage circuit and PWM pulse width modulation control circuit design, ensure that infrared light can be a long time stability
● infrared lamp control and one machine filter synchronization switch to achieve the perfect infrared night vision effect
● The double sun protection structure, infrared light board air-cooled circulation system, aluminum housing heat
● Support RS-485 line fault diagnosis function
● Supports data is not lost
● support 3D intelligent positioning function, to achieve fast locking and tracking of suspicious targets and amplification
● 360 ° continuous rotation of the horizontal direction, vertical direction -2 ° to 90 °, with auto-flip, no surveillance blind spots
● preset speeds of up to 200 ° / s
● the level of keying speed of 0.01 ° ~ 150 ° / s, vertical keying speed of 0.01 ° ~ 100 ° / s
● 255 preset points, data power and memory
● Support 8 cruising scan, each can be added 16 preset points
● Support Proportional zoom function, rotation speed can be adjusted automatically according to zoom multiples
● Optional built-in high-precision RTC clock support 8 timing task
● support Rye function, can stay in the idle state after a specified time automatically run (including power-on into the idle state)
● Night Vision Distance: 120 meters
● Power AC24V ± 10%
